How Many Free Channels Can You Get?

dtv.gov/maps: Find out where the broadcast towers in your area are located.

Antenna Web: Discover how many FREE channels are available from your local broadcasters

Please know before use

The necessary requirements of watching DVB-T TV:

1. It has been using and covering DVB-T mode signal in the country or place where you stay at.

2. The digital TV must be equipped with DVB-T receiver.

3. lf you can not meet NO.2, you must buy a decoder additionally for the signal transformation betweer antenna and TV.

4.If the signal is not satisfying or only a few channels are available, try connecting the amplifier.Keep the TV antenna away from the sources of interference, keep the TV antenna away from those big power consumption devices, such as air conditioner, elevator, hair dryer and microwave oven etc.

5.Antenna signal strength can vary depending on distance from the tower, terrain, and weather. Reposition the antenna in a different location if needed. It is best for the antenna to be in line of sight with the TV tower(s) and avoid obstructions. Always re-scan for channels after moving the antenna.

Specification:

Colour: Black
Material: Plastic
Line length: 3.0M
Size : 320 x 350 x 25mm
Support 1080p HD mode
120 Miles
Connector Type: TV
Frequency range: 174 ~ 240,470 ~ 862 (MHz)
Impedance: 75 ohms
Can receive all "free" channels
Gain: 28DBI
Voltage : 5V
Signal support：DTMB, ATSC, DVB-T, DMB-T, ISDB -T

Set up guide :

Step1 : Connect the end of attached coaxial cable to the ANT/IN connector on the back of the TV or Digital Converter Box, Plug the USV plug into the USB port of the TV or Digital Converber Box.

Step2 : Hand held the antenna, near the window, place it horizontally or vertically.

Step3 : In the TV’s or STB ’s setup menu, set the tuner mode to “ Antenna ” or “ Air ” For more detailed instructions, please refer to your TV manual.

Step4 : In the TV’s or STB ’s setup menu, set TV to “ scan ” for channels. This can sometimes be listed as auto-program,auto-scan,channel search or channel scan. Consult the TV manual or detailed instructions.

Step5 : If reception is sporadic, try moving the antenna to another location and rescanning the TV until optimal postition is found.

Step6 : Fix the antenna at the optimal position you found.

Packing List

Antenna x1
Signal Booster x1
English manual x1
